Victron Phoenix Inverter Compact 24/2000 230V VE.Bus

The Victron Phoenix Inverter Compact 24/2000 230V VE.Bus is a high-efficiency, pure sine wave inverter engineered for professional use and versatile applications. Built using Victron’s proven SinusMax technology, this compact inverter delivers reliable power, high surge capability, and system integration through a VE.Bus communication port.

Designed for space-constrained installations, the Phoenix Compact is ideal for vehicles, boats, caravans, off-grid systems, and backup power solutions where a robust, reliable inverter is required.

SinusMax™ – Superior Engineering

The Phoenix Compact range is developed for professional duty, combining true sine wave output, high efficiency, and compact design. Using hybrid HF technology, Victron achieves a lightweight inverter capable of supplying power to demanding loads without compromise.

Extra High Start-Up Power

A key advantage of SinusMax technology is its high start-up power. This enables the inverter to reliably start difficult loads such as:

• Refrigeration compressors

• Electric motors

• Pumps

• Power tools

Conventional high-frequency inverters often struggle with these loads, but the Phoenix Compact is designed to handle them.

Parallel & 3-Phase Operation (System Scalability)

The Phoenix Compact supports scalable system configurations for higher power demands:

• Up to 6 units in parallel

• 3-phase or split-phase operation

This makes it suitable for large system installations where multiple inverters are required to deliver higher power output.

VE.Bus Communication & Integration

The VE.Bus port enables advanced configuration and system integration. Using the MK3-USB VE.Bus to USB interface cable (sold separately) and Victron software (VictronConnect or VEConfigure), users can customise:

• Output voltage and frequency

• Over- and under-voltage settings

• Programmable relay (alarms, generator start, etc.)

The inverter can also be connected to a GX device (e.g., Cerbo GX) for monitoring and control.

Automatic Transfer Switching Recommendation

If you require automatic transfer switching between AC sources, Victron recommends the MultiPlus inverter/charger, which includes a built-in transfer switch with a <20 ms switchover time, ensuring uninterrupted operation for sensitive electronics.

Key Specifications

• DC Input Voltage: 24V DC

• Continuous Power: 2000 VA

• AC Output Voltage: 230 V

• Waveform: Pure Sine Wave

• Technology: SinusMax hybrid HF

• Communication: VE.Bus

• Parallel / 3-Phase Support: Yes

Models Available

• Power Ratings: 1200VA to 2000VA

• Voltages: 12V or 24V

Ideal Applications

• Off-grid solar systems

• Mobile and marine installations

• Caravans and RVs

• Backup power systems

• Professional and industrial applications
